5T Diesel Forklift
Introduction
TEU 5 ton diesel forklift is very famous for its safety, comfort, environmental protection, good stability and flexible utility. This diesel forklift truck is often used to lift and transport cargoes in the outdoors. Compared with gasoline engine, diesel engine enjoys the advantages of better power performance and low fuel charge. The engine is not easy to flame out even at low speed. It owns strong overload capacity and long-term working capacity. The 5 ton diesel forklift is equipped with 6.494L ISUZU engines, power shift T/M transmissions as well as advanced hydraulic and cooling system.
| SPECIFICATION | Item | FD50T | FD60T | FD70T | FD80T | FD100T | |
| Load capacity | kg | 5000 | 6000 | 7000 | 8000 | 10000 | |
| Load center | mm | 600 | 600 | 600 | 600 | 600 | |
| DIMENSIONS | Max. lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 |
| Free lift | mm | 205 | 205 | 210 | 205 | 205 | |
| Fork size | mm | 1220*150*60 | 1220*150*60 | 1220*150*65 | 1220*170*75 | 1220*175*75 | |
| Overall length(without fork) | mm | 3455 | 3530 | 3590 | 3740 | 4255 | |
| Total width | mm | 1995 | 1995 | 1995 | 1995 | 2245 | |
| Mast height (fork lowering) | mm | 2500 | 2500 | 2500 | 2625 | 2850 | |
| Overall height fork raised | mm | 4420 | 4420 | 4420 | 4545 | 4330 | |
| Height to head guard | mm | 2450 | 2450 | 2450 | 2450 | 2560 | |
| Truck weight | kg | 8050 | 8750 | 9450 | 10450 | 12450 | |
| TIRES | front/rear |
|
4/2 | 4/2 | 4/2 | 4/2 | 4/2 |
| front axle |
|
8.25x15-14PR | 8.25x15-14PR | 8.25x15-14PR | 8.25x15-14PR | 9.00x20-14PR | |
| rear axle |
|
8.25x15-14PR | 8.25x15-14PR | 8.25x15-14PR | 8.25x15-14PR | 9.00x20-14PR | |
| ENGINE | Model |
|
ISUZU 6BG1 | Chaochai 6102 | Mitsubishi S6S-T | Chaochai 6102 | ISUZU 6BG1 |
| Rated power | JIS PS | 112/2000 | 110/2500 | 63.9/2300 | 110/2500 | 112/2000 | |
| Rated torque | JIS kg-m | 42.5/1500 | 36/1650 | 28.5/1700 | 36/1650 | 42.5/1500 | |
| Number of cylinders |
|
6 | 6 | 4.9 | 6 | 6 | |
| Dislacement | L | 6.494 | 5.785 | 6 | 5.785 | 6.494 | |
Optional Engines
5.0T-7.0T: Chinese 6102, Chinese 6110,Isuzu 6BG1,Mitsubishi S6S-T
8.0T-11.5T: Chinese 6110,Isuzu 6BG1
- Competitive Advantages
- Our company has an innovative team who pursuit the best performance. We also provide high-quality and timely service.
- TEU 5 ton diesel forklifts can match with different kinds of engines. This provides multiple choices for customers.
- Designed with hydraulic system, this diesel forklift truck can effectively increase service life and productivity.
- Built-in tilt cylinder makes the driving space much wider.
- High-quality components guarantee good performance of our 5 ton diesel forklifts. The hydraulic components and key parts are acquired from world-renowned manufacturers.
- Integrated control system makes this diesel forklift truck easier to manipulate.
Main Parts of 5 Ton Diesel Forklift
| Engine | It is the power unit of the forklift truck, which converts thermal energy into mechanical energy. |
| Transmission Gear | It includes clutch, transmission, main transmission, differential mechanism, axle shaft, etc. |
| Operating Control | It consists of steering mechanism and brake system. |
| Working Device | It includes inside and outside door frame, fork mounting, pallet fork, lifting chain, roller, pulley and other parts. Its role is to lift or stack cargoes. |
| Hydraulic System | It includes fuel tank, hydraulic pump, distributor, lifting hydraulic cylinder and tilt cylinder. It can realize lifting and tilting of cargoes. |
| Electric System | It consists of power section and the electric part, such as storage battery, alternator, starter motor, ignition device, illumination device and loudspeaker. |
- Operation Attentions
- Customers need to fully know the working environment, the maximum load and the maximum lifting height of the 5 ton diesel forklift and then choose appropriate models and configurations.
- Drivers who have been trained and hold driving license can drive this diesel forklift truck.
- Check each control and alarm device before driving this 5T forklift. If there is damage or defect, it must be operated after repair.
- The pallet fork should insert below the cargoes and make cargoes distribute evenly on the fork. It is prohibited to use a single fork tip to pick the cargoes.
- Stable starting, steering, driving, braking and stopping are quite necessary. When we drive the 5 ton diesel forklift on wet or slippery road, we need to slow down while steering.
- When the FD50T diesel forklift truck loaded with material is driving, we should ensure that the cargoes are lowered and the door frame is inclined to the rear.
- Customers need to pay attention to daily maintenance of this forklift truck.
Packaging and Transportation
Shipping By Container.
As a professional manufacturer and supplier of diesel forklift trucks in China, TEU can provide 1.5 to 10 ton diesel forklifts. In addition to this 5T diesel forklift, we also offer other material handling equipment such as electric forklift, gasoline forklift truck. Till now, we have established exclusive selling agencies in Australia, Russia, the United Kingdom and Northern Ireland, Korea and Iran. Our 5 ton diesel forklifts have been exported to Southeast Asia, South America, Africa and Europe.
