3-Way Electric Stacker
- Description
- Specifications
3-way stacker is a kind of compact forklift that is frequently used to maneuver in smaller spaces. This 3-way battery powdered stacker is a piece of heavy equipment typically used in industrial and manufacturing applications for lifting and placing flat and broad items, such as tubes, pallets, slabs, etc. Our 3-way stacker is designed with maximum loading capacity of 1,500kg, and it’s suitable for medium or highly intensive pallet transport and stacking in warehouses, retail premises and manufacturing factories.
Applications
This 3-way battery powered stacker is typically utilized for indoor applications (such as warehouse industries) to transport and stack pallets from or to storage racks.
Applications
This 3-way battery powered stacker is typically utilized for indoor applications (such as warehouse industries) to transport and stack pallets from or to storage racks.
| Model | RT10 | RT12 | RT15 | |||
| Max. lifting weight | kg | 1000 | 1200 | 1500 | ||
| Load center | mm | 500 | 500 | |||
| Overall length | mm | 2850 | 2850 | 3000 | ||
| Overall (guide wheel included) | mm | 1495 | 1550 | |||
| Overall (overhead guard included) | mm | 2315 | ||||
| Turning radius (external) | mm | 1800 | 1945 | |||
| Overall weight | kg | 3590 | ||||
| Speed | Max. traveling speed | Loaded | km/h | 8 | ||
| Unloaded | km/h | 9 | ||||
| Lifting speed | Loaded | mm/s | 250 | |||
| Unloaded | mm/s | 330 | ||||
| Battery | Voltage/capacity | V-AH/5hr | 48V-400 | 48V-450 | ||
| Weight (battery box included) | kg | 670-720 | 750-800 | |||
| Experiment 1 | 45% power left | |||||||
| Mast | Lifting, loaded | Time 1 | Time 2 | Time 3 | Time 4 | Time 5 | Average time | Speed (mm/s) |
| 3000 | 11.88 | 11.84 | 11.84 | 11.81 | 11.56 | 11.786 | 254.5392839 | |
| Lifting, unloaded | Time 1 | Time 2 | Time 3 | Time 4 | Time 5 | Average time | Speed (mm/s) | |
| 7.53 | 7.16 | 7.53 | 7.44 | 7.5 | 7.432 | 403.6598493 | ||
| Lowering, loaded | Time 1 | Time 2 | Time 3 | Time 4 | Time 5 | Average time | Speed (mm/s) | |
| 7.53 | 7.28 | 7.09 | 7.34 | 7.25 | 7.298 | 411.0715264 | ||
| Lowdering, unloaded | Time 1 | Time 2 | Time 3 | Time 4 | Time 5 | Average time | Speed (mm/s) | |
| 7.78 | 7.5 | 7.59 | 7.53 | 7.38 | 7.556 | 397.0354685 | ||
| Load |
Overall weight (loaded) |
Front axle | Rear axle | |||||
| 4460 | 4010 | 450 | ||||||
|
Overall weight (unloaded) |
Front axle | Rear axle | ||||||
| 2960 | 1420 | 1540 | ||||||
| Traveling speed | Loaded | Unloaded | ||||||
| 16 | 15 |
